概要

仕様

MOZA R9 V3 DDベース

プラットフォーム:パソコン
FFBドライブシステム:ダイレクトドライブ
最大ホイール回転:無限
ピークトルク:9 N·m
ピーク電力:180W
入力電圧:110V~220V AC → 36V DC
USBリフレッシュレート:1000Hz
ホイールベースインジケーターライト:サポートされています
アプリの機能:サポートされています(MOZA Pit House & MOZAモバイルアプリ)
クイックリリース:MOZAクイックリリース
接続ポート:始動スイッチ、電源、データ、緊急停止スイッチ、ディスプレイ画面
ファームウェアの更新:適用可能
温度制御システム:インテリジェント温度モニタリング&アクティブ冷却
エンコーダー:21ビット磁気エンコーダ(1回転あたり2,097,152ステップ)
モータータイプ:高性能サーボモーター(18スロット/16極構成)
ハウジング材質:航空グレードアルミニウム合金
色:
取り付け:4穴底マウント、オプションのテーブルクランプとサイドマウントをサポート
テーブルクランプ:オプション
サイドマウント:オプション
緊急停止スイッチ:オプション
サイズ(長さ×幅×高さ):240 × 157 × 124 mm
付属品:ユーザーマニュアル、保証書、電源、USBケーブル、ツールキット

寸法

R9 V3 寸法

セット内容

  • R9 V3 DD ホイールベース x1

  • 電源

  • ツールキット

  • USBケーブル

  • ユーザーマニュアル

  • 保証書

MOZA R9 V3 と互換性のあるステアリングホイールはどれですか?

R9 V3 は、以下を含むすべての MOZA Racing ステアリングホイールと互換性があります。

MOZA GS V2P / GS GT
MOZA FSR / FSR2
MOZA KS
MOZA CS V2
MOZA RS V2
MOZA ESX
そして今後発売する MOZAユニバーサルホイール

MOZA R9 V3 と Fanatec、Thrustmaster、その他のブランドのハードウェアとの互換性はありますか?

FanatecやThrustmaster、その他ブランドのホイール、ペダル、シフター、その他のアクセサリーをMOZA Racingで使用できるかどうか、よくお問い合わせをいただきます。多くの場合、異なるメーカーのデバイスには互換性がありません。そのため、異なるメーカーの製品を直接接続することはできません。少なくとも、そのような接続方法はサポートされていません。

市場にはこのような組み合わせを可能にするアダプターが存在する可能性がありますが、ハードウェアに使用されている技術や信号許容度が異なるため、たとえ仕様が似ていても、これらのソリューションは信頼できません。MOZA Racingは、サードパーティ製のアダプターや類似のソリューションに関して一切の保証をいたしかねます。もちろん、すべてのデバイス間で可能な限り高い非互換性を実現するよう努めておりますが、これは容易なことではありません。互換性に関するご質問は、製品ページまたはFAQに記載されている情報をご参照ください。

R9 V3 はデスクセットアップに適していますか?

はい。R9 V3はコンパクトなデザインで、デスクユーザーに最適です。デスククランプとマウントアダプターに対応しており、様々な設置環境に柔軟に対応します。

R9 V3 の最大トルクはどれくらいですか? また、どのような種類のゲームに最適ですか?

R9 V3は最大トルク9Nmを発揮し、F1、GT、ラリー、ストリート レース ゲームなど、さまざまなレーシング シミュレーションに最適です。

MOZA R9 V3 は他の MOZA エコシステム製品と連携できますか?

はい。R9 V3は、ペダル、シフター、ダッシュボードディスプレイなど、MOZA Racingエコシステムと完全に互換性があります。すべてのデバイスは、MOZA ピットハウスソフトウェアで設定できます。

Customer Reviews

Based on 227 reviews
90%
(205)
8%
(18)
1%
(2)
0%
(0)
1%
(2)
G
Georgi

Will give 1 star due the the amount of software bugs that they have. From one update the base randomly disconnects, then something with the pedals then something else... Considering to sell them to someone else so I can get something more reliable and without so many bugs. The quality of products is not bad, unfortunately the software is trash. If they can make it work would be great deal, until then I would never recommend them to someone else.

K
Khalid

Very nice 😍

A
Anonymous

Every time force feedback disconnect right as i race cannot do anything lost myself lots of rankcannot fix it

Dear racing enthusiast,

We’re very sorry to hear about the disconnection issue you’ve experienced with your R9 V3, especially during races. We understand how frustrating this must be.

Have you already reached out to our support team? Please submit a ticket via support.mozaracing.com or contact us by support@mozaracing.com, and our engineers will assist you with checking connections, firmware versions, and possible solutions.

We’re committed to helping you get back to a smooth and stable racing experience.

Thanks
MOZA Team

G
Gary B.

I have had the R9 since March 2022 and its never had a problem and still running great, I think this year is time to upgrade. Love my moza

A
Anonymous

Loving this thing so far. Very sturdy and super responsive. It was easy to set up and mounted well with my frame.

A
Abdulaziz

Coming for belt driven base this is actually quite an upgrade the only issue it came with an American outlet while in my country it a uk outlet

A
Anonymous

Easy to use and responsive.

B
Ben

Amazing product, great upgrade from the entry level wheel I had, and super fast delivery
